355mm Hydraulic Butt Welding Machine/Hot Melting Machine

 ModelHDC355Pipe size(mm)140mm,160mm,180mm,200mm,225mm,250mm,280mm,315mm,355mmHeating plat Max temp270ºCTemp deviation in surface(170-250)±5ºCMax tolerance of welding jointing0.3MMMax working pressure hydraulic station6MpaWorking voltage220VWorking frequency50-60HZMotor power/voltage of hydraulic station0.7

Featured Products


ModelHDC355
Pipe size(mm)140mm,160mm,180mm,200mm,225mm,250mm,
280mm,315mm,355mm
Heating plat Max temp270ºC
Temp deviation in surface(170-250)±5ºC
Max tolerance of welding jointing0.3MM
Max working pressure hydraulic station6Mpa
Working voltage220V
Working frequency50-60HZ
Motor power/voltage of hydraulic station0.75KW / 220V
Power/voltage of heating plate3KW / 220V
Power/voltage of planning tool motor1.2KW / 220V
Total Power4.95KW
Overall weight of machine(kg)245KGS
355mm Hydraulic Butt Fusion Welding Machine/ Termofusion Machine

Application&Features:
1.Consists of basic frame, milling cutter, heating cutter, heating plate, hydraulic unit, support.
2.Working environment must be between -40ºC-40ºC.
3.Pressure adjustable range: 0-6 Mpa.
4.Heating plate Max. temperture:270ºC.
5.Suitable for material of PE,PP, PVDF.


355mm Hydraulic Butt Fusion Welding Machine/ Termofusion Machine


355mm Hydraulic Butt Fusion Welding Machine/ Termofusion Machine

355mm Hydraulic Butt Fusion Welding Machine/ Termofusion Machine
355mm Hydraulic Butt Fusion Welding Machine/ Termofusion Machine
