Acdc high frequency lift shock pulse TIG-250 MMA inverter welding machine cold welding

Features:1). Adopt High performance 32-bit MCU digital technology, and IGBT & advanced PWM inverter technology, 3PCB structure with high duty cycle, suitable for professional welding and easy to repair.2). Multi-function for precision welding, DC MMA, DC TIG, DC PULSE TIG, AC TIG, AC&n

Featured Products

Acdc High Frequency Lift Striking Pulse TIG-250 MMA Inverter Welding Machine with Cold Welding


Acdc High Frequency Lift Striking Pulse TIG-250 MMA Inverter Welding Machine with Cold Welding
Features:
1). Adopt High performance 32-bit MCU digital technology, and IGBT & advanced PWM inverter technology,
3PCB structure with high duty cycle, suitable for professional welding and easy to repair.
2). Multi-function for precision welding, DC MMA, DC TIG, DC PULSE TIG, AC TIG, AC PULSE TIG,
and 10 + 10 Channels customized Program Store to convenient for operating.
3), Easy-to-user interface, Digital set of Pre-Gas Time, Start Current, Up Slope and Down Slope Time, Finish Current Level and Post Gas Time with the choice of 2T or 4T trigger function allows controlling the start and finish of the weld process at a professional level. Digital Pulse Frequency Control gives full parameter setting of Peak Current, Base Current, Pulse Frequency and Pulse Width, allowing control of heat input into the work for penetration control and minimizing distortion, gain the ideal balance between cleaning the aluminum surface of oxide.
4). Unique housing design with high-strength plastic All-around corner protection, innovative human engineering handle.
5). Selectable Multi-Waveform output to meet different job:
Sine wave, Square wave, trapezoidal wave and triangular wave.
Acdc High Frequency Lift Striking Pulse TIG-250 MMA Inverter Welding Machine with Cold Welding

7). Excellent performance for aluminum and magnesium welding, special for thin plate welding.
8). AC balance (15-50%) control monitors the oxide and helps better cleaning during Aluminum welding.
9). Good Arc-stiffness and concentrated heat; Stable Arc without spatter, good shaping and less deformation.
10). Weld with various materials such as Aluminum, magnesium, steel, stainless steel, titanium, cooper, nickel       and their alloys.

11). With Wide Voltage Function, work well and stably between voltage 150V-270V or together with Generator.
12). With foot pedal control and automatic detection, switch function, Perfect when doing pipe welding.
pedal control can be optional.
Acdc High Frequency Lift Striking Pulse TIG-250 MMA Inverter Welding Machine with Cold WeldingAcdc High Frequency Lift Striking Pulse TIG-250 MMA Inverter Welding Machine with Cold Welding
ModelMCU TIG-160 AC/DC PULSEMCU TIG-200 AC/DC PULSEMCU TIG-250 AC/DC PULSE
Input Voltage(V)1*110V-130V/220V-240V 1*110V-130V/220V-240V 1*110V-130V/220V-240V
Frequency (Hz)50/6050/6050/60
Power Capacity (KVA)57.18.5
Max Input Current (A)223134
TIG/MMA Current range(A)5~160 / 20~1605~200 / 20~1805~230 / 20~200
ARC Force
Current range(A)
0-1000-1000-100
No-load Voltage(V)656565
Rated Duty Cycle (%)606060
Pulse Frequency (Hz)0.5~10000.5~10000.5~1000
Pulse Duty (%)10~9010~9010~100
AC TIG Frequency (Hz)0.5~2500.5~2500.5~250
AC TIG Balance (%)15~5015~5015~50
Up/Down Slope Time(S)0.0~15.0 0.0~15.0 0.0~15.0
Pre/Post Flow Time(S)0.1~15.00.1~15.00.1~15.0
Basic current range (%)10-9010-9010-90
Remote controlYesYesYes
Memory FunctionYesYesYes
Efficiency (%)858585
Power Factor0.930.930.93
Protection Class(S)IP23IP23IP23
Insulation ClassFFF
Dimension(mm)465*190*280465*190*280515*190*280
Weight (Kg)121214
AccessoriesTIG-26 TORCH WITH 4M CABLE, ELECTRODE HOLDER WITH 2M CABLE,
EARTH CLAMP WITH 2M CABLE, 3M GAS HOSE, 2PCS HOSE CLAMP.
MOQ50Pcs50Pcs50Pcs
FOB Price: Steel Panels
FOB Price: Plastic Panels
