CNC Automatic Butt Fusion Welding Machine

CNC Automatic Butt Fusion Welding Machine


USES and features:


1 Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF material.

2  Consists of basic frame, CNC control, hydraulic unit, planing tool, heating plate, basket & optional parts.

3  Equipped with SIEMENS PLC and touch screen control system.

4  Real-time data printing, recording function and USB port available.

5  Pre-installed welding standard such as CTSG, ISO, DVS, GIS, etc.

6  Hydraulic heating plate system, full automatic process.

7  Standard with single inserts to improve the accuracy of pipeline alignment.

8  BDS/GPS Positioning and remote data transmission function available.

9  Fingerprint, identification of operators.

10 Part of SMART GAS-CLOUD WELDING system, easy extension.

Technical parameters
ModelQZD355
Pipe size90mm, 110mm, 160mm, 180, 200, 225, 250, 280, 315, 355
Heating plate Max. temp.270ºC
Temp. deviation in surface (170-250ºC)≤±7ºC
Pressure adjustable ranges0.4-6Mpa
Working voltage220V 50Hz
Heating plate power4KW
Planing tool power1.1KW
Hydraulic unit power0.75KW
Total power5.85KW

Packing list
ItemDimension with packing(mm)N.W(kg)G.W(kg)Remark
1920×350×5104562Basic frame (include liner)
2500×450×5001731Heating plate,planing tool, support, attachments
3800×600×7006080Hydraulic unit
Total0.613CBM122173

CNC Automatic Butt Fusion Welding Machine
CNC Automatic Butt Fusion Welding Machine


Certificate
CNC Automatic Butt Fusion Welding Machine
Company

Our company is the leader manufacturer of butt fusion equipment in china.We occupy the 70% domestic market and export to more than 45 countries.we specialize in producing a complete range of international standard butt fusion equipment including field welding machine,workshop fitting machine,pipe saw,all the optional parts and tools required under the ISO9001 system and approved to CE standards by SGS.


In 2015, my company joined German ROTHENBERGER tools group, becoming one of the more than 50 companies under the first European big pipe tool production and sellers. with the German headquarters and subsidiaries throughout the world to work together, we will further development of domestic and international market.
