Brief:
1.Suitable for welding of plastic pipes and fittings made from PE, PP & PVDF.
2. Be made of Aluminum material, easy to carry and transport.
3.Consists of Planning Tool,Heating Plate,Basic Frame,Hydraulic Unit and Support.
Feature:
1.Removable PTFE coated heating plate with separate temperature control system.
2.Electric Planning Tool with reversiable double cutting edge blades.
3.Hydraulic Unit provides welding machine with compressing power.
4.Be made of Aluminum material,esay to carry and transport.
5.Low starting pressure ensures reliable welding quantity of small pipes.
6.Temperature Controller and Timer,easy to know the exact time and temperature.
| Type | SUD355H |
| Materials | PE,PP,PVDF |
| Welding range of diameter | 90 110 125 140 160 180 200 225 250 280 315 355mm |
| Environment temp. | -5~45ºC |
| Power supply | ~220V±10 %,50 Hz |
| Total power | 5.45 kW |
| Include:Heating plate | 3.6 kW |
| Trimmer | 1.1 kW |
| Hydraulic unit | 0.75 kW |
| Dielectric resistance | >1MΩ |
| Max. Pressure | 6.3 MPA |
| Max. Temperature of heating plate | 270ºC |
| Difference in surface temperature of heating plate | ±5ºC |
| Package Volume | 1.1CBM(2 plywood cases) |
| Gross Weight | 260kg |
